Not sure I would have done this level of work to a 1.9, maybe on a Z3M though???
https://www.facebook.com/StiptPolishPoint/posts/1680552755345993
https://www.facebook.com/StiptPolishPoint/posts/1680552755345993
Wow wow wow! Stunning on a biblical scale! Love the colour. Note too self, must work harder ......... much harder
Not sure how everyone spent the beautiful weather, but I was stuck at home polishing my tips
Last edited by a moderator:
And spraying the handles back to black
Last edited by a moderator:
Love the knobbly knee shot, had to do a double take though ....
- Joined
- Oct 19, 2014
- Points
- 174
- Model of Z
- 2.2i Sport
Good grief.
Life isn't long enough for that.
Good write up !
So I checked another thing off the list of pointless tasks to do but something i wanted to do.
I changed the Diff oil. After 16 years but only 38k miles, i thought why not.
3 things i learned though. I will never do it again because of the smell, don't trust an aussie for parts and my spare tyre cannot be removed.
I am fortunate to have a pit at home making the job a lot easier to complete, but it also means that any Diff oil stinks out the house in a similar fashion to a gas leak smell. Not pleasant and i'm burning through candles and frebreeze to dispose of it.
I bought new gaskets from a buyer on eBay based in Australia, these were rubber gaskets and to my surprise did not hold up to the torque setting when refitting, so the original metal gaskets got a clean and were refitted. No leaks so far.
The spare tyre was restricing my ability to use the torque wrench, i thought it would be an easy task to remove, but the 16mm bolt in the wheel well is firmly rusted in place, so i had to tighten up without removing the tyre. Oh what an hour this simply oil change was meant to be.
Things to note, i nearly used 2L of oil, not sure if that's is because mine needed more against the handbook guideline because it has a LSD?
There are 2 types of gasket, rubbers and metal. Be sure to know which you have before starting the job, or like me you try to replace a gasket, after filling the diff with oil, probably the cause for the smell. Change your diff oil at a garage our outside to avoid contamintation in your house.
Note the slight rub from trying to take off the nut, the spare wheel is a new task to remove
Rubber washer did not stand up to 70nm torque
Love having a pit to use!
The oil on the way out wasn't too bad a colour i thought. Probably could have stayed without a worry.
I changed the Diff oil. After 16 years but only 38k miles, i thought why not.
3 things i learned though. I will never do it again because of the smell, don't trust an aussie for parts and my spare tyre cannot be removed.
I am fortunate to have a pit at home making the job a lot easier to complete, but it also means that any Diff oil stinks out the house in a similar fashion to a gas leak smell. Not pleasant and i'm burning through candles and frebreeze to dispose of it.
I bought new gaskets from a buyer on eBay based in Australia, these were rubber gaskets and to my surprise did not hold up to the torque setting when refitting, so the original metal gaskets got a clean and were refitted. No leaks so far.
The spare tyre was restricing my ability to use the torque wrench, i thought it would be an easy task to remove, but the 16mm bolt in the wheel well is firmly rusted in place, so i had to tighten up without removing the tyre. Oh what an hour this simply oil change was meant to be.
Things to note, i nearly used 2L of oil, not sure if that's is because mine needed more against the handbook guideline because it has a LSD?
There are 2 types of gasket, rubbers and metal. Be sure to know which you have before starting the job, or like me you try to replace a gasket, after filling the diff with oil, probably the cause for the smell. Change your diff oil at a garage our outside to avoid contamintation in your house.
Note the slight rub from trying to take off the nut, the spare wheel is a new task to remove
Rubber washer did not stand up to 70nm torque
Love having a pit to use!
The oil on the way out wasn't too bad a colour i thought. Probably could have stayed without a worry.
- Joined
- Feb 18, 2016
- Points
- 231
- Model of Z
- Z3M Imola and Z4 (e89)
I'd say that's not the original oil after doing 6 or so zed diffs to date. Very clean. Still worth doing though, done mine twice in the last 2 years.
The garage finally had the upgrade it needed. I can now see all the imperfections on my car in the garage rather than taking it outside. £54 never made such a big difference before!
Fortunately it came with the house when we bought it, but it was built in time when the garage was further left, the pit is not centre so cars have to be angled in to work under@Ryan , did you "retrofit" the pit? Looks like a great thing to have.
I dug the pit on my garage about 30 years ago. Wouldn't want to do it again though.
Tony.
Tony.
Some winter work has finally begun, i've managed to remove the rear wheel arch, add a nut, bolt and washer because the rear bumper wasn't neatly attached in the corners, looks like on a previous respray some screws had broken off and not been replaced.
Removed the passenger seat to replace the bushings, FYI:
View: https://www.youtube.com/watch?v=n6PsUywdt74
great video if anyone else has a bit of rocking that they don't want to have
And i masked up and gave the door handles a refresh with some black paint, help to get rid of the fade
There is one thing i'd like to ask the audience on, when i took off the back wheel on the passenger side, i noticed something on the back of my exhaust, anyone have a clue as to what it is or why it's there?
Removed the passenger seat to replace the bushings, FYI:
great video if anyone else has a bit of rocking that they don't want to have
And i masked up and gave the door handles a refresh with some black paint, help to get rid of the fade
There is one thing i'd like to ask the audience on, when i took off the back wheel on the passenger side, i noticed something on the back of my exhaust, anyone have a clue as to what it is or why it's there?
I certainly have one on the back of my 2.2. It's a vibration damper apparently
- Joined
- Oct 19, 2014
- Points
- 174
- Model of Z
- 2.2i Sport
Same on mine, it was flopping about so I unbolted it and the car still works so I don't worry. Too much.
It’s less of a worry and more of a what the hell is that? Especially as it isn’t attached to the body in any way, only the exhaust. Thanks @Mint
Nice for my car to have some company in the office car park - it seems everyone is getting their 2nd cars out
Great thread Ryan, really enjoyed the read
