Door won't unlock

Discussion in 'Z4 Roadster & Coupé' started by 53dke, Mar 30, 2013.

  1. 53dke

    53dke Regular Member

    Joined:
    Mar 9, 2013
    Messages:
    20
    Likes Received:
    0
    Trophy Points:
    12
    I have a 2003 z4 and the drivers door wont unlock with the remote, the passenger door unlocks and both doors will lock with the remote , the drivers door will unlock with the key.

    Anybody help?

  2. GazHyde

    GazHyde The Gaz Monkey
    Staff Member Administrator Global Moderator British Zeds

    Joined:
    Dec 2, 2011
    Messages:
    15,163
    Likes Received:
    9,256
    Trophy Points:
    226
    Location:
    Newbury, Berkshire
    Model of Z:
    BMW Z4 3.0Si Sport
    Sounds like the door lock actuator to me. Have the same on my Z3, which is more common. Drivers door and boot open from the remote, but nothing from the passenger door.

  3. hard top

    hard top Zorg Expert (I)
    Dutch Zeds The M44 Massive

    Joined:
    Dec 5, 2011
    Messages:
    20,779
    Likes Received:
    6,060
    Trophy Points:
    213
    Location:
    Netherlands
    One of these.....

    [​IMG]

    ;)

  4. Titan

    Titan Moderator
    British Zeds

    Joined:
    Dec 4, 2011
    Messages:
    1,409
    Likes Received:
    107
    Trophy Points:
    86
    Location:
    North North Yorkshire
    Model of Z:
    sDrive35i
    I'm not convinced Gary
    As the driver's actuator solenoid is working but only in "lock" mode. I suspect a wiring fault rather than the actuator itself.
    Do Z4s suffer from the same wiring harness fracture problem at the boot lid/body interface that Z3s do?
    Is there another place where repetitive movement may have caused a fatigue failure in the wiring loom?
    Unless it is easy to get at the actuator inside the door panel and test it, I would be inclined to look elsewhere for a cause first.

  5. GazHyde

    GazHyde The Gaz Monkey
    Staff Member Administrator Global Moderator British Zeds

    Joined:
    Dec 2, 2011
    Messages:
    15,163
    Likes Received:
    9,256
    Trophy Points:
    226
    Location:
    Newbury, Berkshire
    Model of Z:
    BMW Z4 3.0Si Sport
    Titan,

    Not sure on the wiring routes in the boot regarding door locks, I personally haven't come across any Z4's with that particular issue.

    I know from personal experience that a lot of the wiring loom passes through the boot area. A cable being chopped by the boot lid mechanism was the cause of the amplifier failure in mine (amplifier is in the battery well in the boot). Took hours of being plugged in to a BMW diagnostics machine to locate that fault!

    Only experience I've come across with Z4 door locks tends to be the actuator. That said, I agree that you can't rule out a wiring loom fault!

  6. jonco

    jonco Zorg Guru (III)
    Supporter British Zeds The M44 Massive

    Joined:
    Dec 6, 2011
    Messages:
    1,334
    Likes Received:
    669
    Trophy Points:
    149
    Location:
    Chester
    Model of Z:
    '98 1.9 Auto
    If it were a Z3, my money would be on the loom from body to boot as Titan suggests and is a common fault - but admit I have no experience of the 4.

    A quick check worth trying ( but not guaranteed) is to flex the loom at body to boot lid transition and see if symptoms change. Worked for me on the 3 as continuity was making and breaking - also cheaper than BMW diagnostics.

    Another one is to remove a cover and find unsheathed section of cable then gently pull on each core in turn. There are 9 on the Z3 - 2 for central brake light and rest for boot lock and return circuit.


    Good Luck

  7. 53dke

    53dke Regular Member

    Joined:
    Mar 9, 2013
    Messages:
    20
    Likes Received:
    0
    Trophy Points:
    12
    Will give it a try with the cable, the problem I have now is that the battery is totally flat, the car has been parked up for 5 months, I have had it on charge for 8 hrs but still nothing, I have jump started it ok and been for a drive around for half an hour, car wouldn't start in the morning. I have been told that the battery may be stratified and will need a deep charge so I am going to invest in a Ctek charger conditioner which can be left on charge for long periods, anybody have any experience of this charger?

  8. GazHyde

    GazHyde The Gaz Monkey
    Staff Member Administrator Global Moderator British Zeds

    Joined:
    Dec 2, 2011
    Messages:
    15,163
    Likes Received:
    9,256
    Trophy Points:
    226
    Location:
    Newbury, Berkshire
    Model of Z:
    BMW Z4 3.0Si Sport
    If the battery has completely flattened for a period of time, you may experience another small issue. If when power is returned, you don't have full use of the air con, heater and some other controls your car has entered "transport mode".

    The reason behind transport mode is that it stops the batteries flattening on brand new cars while they are being delivered from the factory/dealer to the new owner. Basically shuts down things that could put a drain on the battery if accidentally turned on in transit.

    If you do get this, then it's either a BMW dealer or someone with diagnostic software to switch off.

    I think you will be ok but I get emails from club members about it regularly!

  9. 53dke

    53dke Regular Member

    Joined:
    Mar 9, 2013
    Messages:
    20
    Likes Received:
    0
    Trophy Points:
    12
    Finger crossed then, thanks
